boolean DMX_FadeChannel (integer $InstanceID, integer $Channel, integer $Value, float $FadeTime)
|InstanceID||ID of the device to be switched|
|Channel||0 = all module channels, 1 – 512 depending on configuration|
|FadeTime||Time in seconds|
|If the command succeeds, it returns TRUE, otherwise FALSE.|
Dims the Channel of the device with ID InstanceID to __Value with a certain FadeTime
DMX_FadeChannel(12345, 0, 255, 2.5); //Dim all channels of the module to 255 in 2,5 sec
