DMX_FadeChannelDelayed

boolean DMX_FadeChannelDelayed (integer $InstanceID, integer $Channel, integer $Value, float $FadeTime, float $DelyTime)

Parameters

InstanceID ID of the device to be switched
Channel 0 = all module channels, 1 – 512 depending on configuration
Value 0-255
FadeTime Time in seconds
DelyTime Time in seconds

Returns

If the command succeeds, it returns TRUE, otherwise FALSE.

Description

Dims the Channel of the device with ID InstanceID to __Value with a certain FadeTime. You can specify a DelayTime after which the dimming starts.

When no delay time is set this command will abort all pending fading which were queued by DMX_FadeChannelDelayed. This allows creating a new queue of fadings. This hint is only relevant when using fadings with delay time

Example

//Dims a module completely down and back up.
DMX_FadeChannel(12345, 0, 255, 5.0); //Dim all channels of the module to 255 in 2,5 sec
DMX_FadeChannelDelayed(12345, 0, 0, 2.5, 5); //Dim all channels of the module to 0 in 2,5sec., after a delay of 5sec.
