boolean DMX_FadeRGB (int $InstanceID, int $R, int $G, int $B, float $FadeTime)
| InstanceID | ID of the device to be switched |
| R | Brightness value 0 (off) to 255/65535 (8/16 bit) (on, maximum brightness) |
| G | Brightness value 0 (off) to 255/65535 (8/16 bit) (on, maximum brightness) |
| B | Brightness value 0 (off) to 255/65535 (8/16 bit) (on, maximum brightness) |
| FadeTime | Time in seconds |
If the command succeeds, it returns TRUE, otherwise FALSE.
Dims the red, green and blue channels of the ID InstanceID with a certain FadeTime.
// Fade color to yellow in 5 seconds
// 8bit instance
DMX_FadeRGB(12345, 255, 255, 0, 5.0);
// 16bit instance
DMX_FadeRGB(12345, 65535, 65535, 0, 5.0);
