DMX_FadeRGB

boolean DMX_FadeRGB (integer $InstanceID, integer $R, integer $G, integer $B, float $FadeTime)

Parameters

InstanceID ID of the device to be switched
R Brightness value 0 (off) to 255/65535 (8/16 bit) (on, maximum brightness)
G Brightness value 0 (off) to 255/65535 (8/16 bit) (on, maximum brightness)
B Brightness value 0 (off) to 255/65535 (8/16 bit) (on, maximum brightness)
FadeTime Time in seconds

Returns

If the command succeeds, it returns TRUE, otherwise FALSE.

Description

Dims the red, green and blue channels of the ID InstanceID with a certain FadeTime.

Example

// Fade color to yellow in 5 seconds
// 8bit instance
DMX_FadeRGB(12345, 255, 255, 0, 5.0);

// 16bit instance
DMX_FadeRGB(12345, 65535, 65535, 0, 5.0);
