Dokumentation

Geräteliste

Unterstützte Gateways

Produkt Beschreibung
EnOcean LAN Gateway (TCM310 LAN Gateway)
Produktinformation | Jetzt bestellen
IP Gateway
BSC-BOR USB Gateway
EnOcean USB300 USB Gateway
EnOcean FGW14 (mit FAM14) USB/Seriell Gateway (Betriebsart 6) und
Funkerweiterung FAM14 (Betriebsart 3)
TCM130 Alle Geräte die das ESP2 Protokoll unterstützen
TCM310 Alle Geräte die das ESP3 Protokoll (Dolphin) unterstützen
Thermokon STC-Ethernet IP Gateway

Unterstützte Geräte

Folgende Geräte wurden auf Ihre Kompatibilität mit IP-Symcon untersucht.
Auf Anfrage überprüfen wir gerne weitere, nicht aufgelistete, Geräte.

Allgemein

Produkt Beschreibung
PTM 200 Button/Expert
PTM 200 Shalter
RCM 1xx Schaltaktor (Universell)
STM100 Sensor
STM250 Sensor

alphaEOS

Produkt Beschreibung
Drive B2 Funkstellantrieb
SENSE TF-H Raumklima-Sensor (Temperatur und Luftfeuchtigkeit)

Eltako

Produkt Beschreibung EEP Nummer (Siehe EEP Liste unten)
DSZ14DRS Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
DSZ14WDRS Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
F2L14 RS485-Bus-Aktor 2-Stufen-Lüftungsrelais eigenständiges Modul
F4HK14 4-Kanal-Heiz-Kühl-Relais eigenständiges Modul
F4T65 Funksensoren batterie-/leitungslos EEP: F6-02-01
FABH65S Außen-Bewegungs-Helligkeitssensor eigenständiges Modul
FADS60-230V Funkaktor für Außen-Dämmerungssensor eigenständiges Modul
FAE14LPR Einzelraumregelung Heizen/Kühlen für 2 Zonen eigenständiges Modul
FAE14SSR Einzelraumregelung Heizen/Kühlen für 2 Zonen mit Solid-State-Relais eigenständiges Modul
FAFT60 Außen-Feuchte-Temperatursensor eigenständiges Modul
FAH60 Außen-Helligkeitssensor eigenständiges Modul
FAH60B Außen-Helligkeitssensor eigenständiges Modul
FAH63 Außen-Helligkeitssensor eigenständiges Modul
FAH65S Außen-Helligkeitssensor eigenständiges Modul
FASM60 Funk-Außen-Sendemodul EEP: F6-02-01
FBH65B Bewegungs-Helligkeitssensor eigenständiges Modul
FBH65S Bewegungs-Helligkeitssensor eigenständiges Modul
FBH65TFB Bewegungs-Helligkeitssensor eigenständiges Modul
FCO2TF65 CO2-Sensor EEP: A5-09-04
FFR14 RS485-Bus-Aktor Feldfreischalter eigenständiges Modul
FFR61-230V Feldfreischalter eigenständiges Modul
FHF Funksensor Fenstergriff EEP: F6-10-00
FHK14 Funkaktor für Heiz-Kühl-Relais eigenständiges Modul
FHK61SSR-230V Funkaktor für Heiz-Kühl-Relais eigenständiges Modul
FHK61U-230V Funkaktor für Heizrelais eigenständiges Modul
FIFT65S Innen-Feuchte-Temperatursensor eigenständiges Modul
FIH65S Außen-Helligkeitssensor eigenständiges Modul
FIH65B Innen-Helligkeitssensor EEP: A5-06-02
FKC Funk-Kartenschalter eigenständiges Modul
FKF Funk-Kartenschalter eigenständiges Modul
FLC61-230V Funk-Licht-Controller eigenständiges Modul
FMS14 RS485-Bus-Aktor Multifunktions-Stromstoß-Schaltrelais eigenständiges Modul
FMS61NP-230V Funkaktor Multifunktions-Stromstoßschalter eigenständiges Modul
FMZ14 RS485-Bus-Aktor Multifunktions-Zeitrelais eigenständiges Modul
FMZ61-230V Funkaktor Multifunktions-Zeitrelais eigenständiges Modul
FRGBW71L Dimmaktor eigenständiges Modul
FRW Funksensor Rauchwarnmelder eigenständiges Modul
FSB14 Aktor für Beschattungselemente und Rollladen eigenständiges Modul
FSB61 Funkaktor für Beschattungselemente und Rollladen eigenständiges Modul
FSB71 Funkaktor für Beschattungselemente und Rollladen eigenständiges Modul
FSDG14 Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
FSG14/1-10V Dimmaktor eigenständiges Modul
FSG71/1-10V Dimmaktor eigenständiges Modul
FSM14 Funk-Sendemodul EEP: F6-02-01
FSM60B 4-Kanal Eingang EEP: A5-30-03
FSM61 Funk-2fach-Sendemodul EEP: F6-01-01
FSR14SSR RS485-Bus-Aktor 2-Kanal-Stromstoß-Schaltrelais geräuschlos eigenständiges Modul
FSR14-2x RS485-Bus-Aktor 2-Kanal-Stromstoß-Schaltrelais eigenständiges Modul
FSR14-4x RS485-Bus-Aktor 4-Kanal-Stromstoß-Schaltrelais eigenständiges Modul
FSR61-230V Funkaktor für Stromstoß-Schaltrelais eigenständiges Modul
FSR61/8-24V Funkaktor für Stromstoß-Schaltrelais eigenständiges Modul
FSR61LN-230V Funkaktor für Stromstoß-Schaltrelais eigenständiges Modul
FSR61NP-230V Funkaktor für Stromstoß-Schaltrelais eigenständiges Modul
FSR61VA Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
FSR61VA-10A Funkaktor für 10A-Stromstoß-Schaltrelais eigenständiges Modul
FSR71 Funkaktor für 2-Kanal-Stromstoß-Schaltrelais eigenständiges Modul
FSS12 Funk-Stromzähler-Sendemodul EEP: A5-12-01
FSSA-230V Funkaktor Steckdosen-Schaltaktor eigenständiges Modul
FSU14 RS485-Bus-Display-Schaltuhr EEP: A5-13-04
FSU65D Funksensor Schaltuhr mit Display EEP: F6-01-01
FSUD-230V Dimmaktor eigenständiges Modul
FSVA-230V Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
FT-FTSB Tipp-Funk Feuchte-Temperatursensor EEP: A5-04-02
FT4F Funksensor Flächen-Funktaster EEP: F6-02-01
FT55 Funksensor Flächen-Funktaster EEP: F6-02-01
FTF65S Temperatur-Sensor EEP: A5-02-05
FTK Funk-Fenster-Türkontakt EEP: D5-00-01
FTKB Funk-Fenster-Türkontakt EEP: D5-00-01
FTKE Funk-Fenster-Türkontakt EEP: F6-10-00
FTN14 RS485-Bus-Aktor Treppenlicht-Nachlaufschalter eigenständiges Modul
FTN61NP-230V Funkaktor Treppenlicht-Nachlaufschalter eigenständiges Modul
FTR65DS Funksensor Temperatur-Regler eigenständiges Modul
FTR65HS Funksensor Temperatur-Regler eigenständiges Modul
FTR78S Funk-Temperatur-Regler mit Drehrad EEP: A5-10-03
FUD14 Dimmaktor eigenständiges Modul
FUD14-800W Dimmaktor eigenständiges Modul
FUD61NP Dimmaktor eigenständiges Modul
FUD61NPN Dimmaktor eigenständiges Modul
FUD71 Dimmaktor eigenständiges Modul
FUTH65D Funksensor Uhren-Thermo-Hygrostat eigenständiges Modul
FWS61 Funk-Wetterdaten-Sendemodul EEP: A5-13-01, A5-13-02
FWZ12 Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
FWZ14 Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
FZK14 RS485-Bus-Aktor Zeitrelais für Kartenschalter/Rauchwarnmelder eigenständiges Modul
FWZ61 Funk-Wechselstromzähler-Sendemodul EEP: A5-12-01
FZK61NP-230V Funkaktor für Zeitrelais mit Kartenschalter/Rauchwarnmelder eigenständiges Modul
FZS Funksensor Zugschalter eigenständiges Modul

Hoppe

Produkt Beschreibung
FHF Fenstergriff

HORA

Produkt Beschreibung
SmartDrive MX Stellantrieb

Kieback & Peter

Produkt Beschreibung
MD15 Kleinstellantrieb

Thermokon

Produkt Beschreibung
SR04 Temperatur/Feuchtigkeit
SAB02 Stellantrieb
Thanos Raumbediengerät

EEP

Alle Geräte die folgende EEPs verwenden werden von IP-Symcon unterstützt.

Aktoren

Neu Alt Beschreibung
A5-20-12 07-20-12 Temperature Controller Input

Bi-Direktional

Neu Alt Beschreibung
A5-20-01 07-20-01 Battery Powered Actuator
D2-01-00 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-01 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-02 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-03 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-04 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-05 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-06 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-07 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-08 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-09 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-0A Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-0B Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-0C Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-0D Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-0E Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-0F Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-10 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-11 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-12 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-13 Electronic switches and dimmer with Energy Measurement and Local Content
D2-01-14 Electronic switches and dimmer with Energy Measurement and Local Content
D2-06-01 Multisensor Window Handle - Alarm, Position Sensor, Vacation Mode, Optional Sensors

Sensoren

Neu Alt Beschreibung
A5-02-01 07-02-01 Temperature Sensor Range -40°C to 0°C
A5-02-02 07-02-02 Temperature Sensor Range -30°C to +10°C
A5-02-03 07-02-03 Temperature Sensor Range -20°C to +20°C
A5-02-04 07-02-04 Temperature Sensor Range -10°C to +30°C
A5-02-05 07-02-05 Temperature Sensor Range 0°C to +40°C
A5-02-06 07-02-06 Temperature Sensor Range +10°C to +50°C
A5-02-07 07-02-07 Temperature Sensor Range +20°C to +60°C
A5-02-08 07-02-08 Temperature Sensor Range +30°C to +70°C
A5-02-09 07-02-09 Temperature Sensor Range +40°C to +80°C
A5-02-0A 07-02-0A Temperature Sensor Range +50°C to +90°C
A5-02-0B 07-02-0B Temperature Sensor Range +60°C to +100°C
A5-02-10 07-02-10 Temperature Sensor Range -60°C to +20°C
A5-02-11 07-02-11 Temperature Sensor Range -50°C to +30°C
A5-02-12 07-02-12 Temperature Sensor Range -40°C to +40°C
A5-02-13 07-02-13 Temperature Sensor Range -30°C to +50°C
A5-02-14 07-02-14 Temperature Sensor Range -20°C to +60°C
A5-02-15 07-02-15 Temperature Sensor Range -10°C to +70°C
A5-02-16 07-02-16 Temperature Sensor Range 0°C to +80°C
A5-02-17 07-02-17 Temperature Sensor Range +10°C to +90°C
A5-02-18 07-02-18 Temperature Sensor Range +20°C to +100°C
A5-02-19 07-02-19 Temperature Sensor Range +30°C to +110°C
A5-02-1A 07-02-1A Temperature Sensor Range +40°C to +120°C
A5-02-1B 07-02-1B Temperature Sensor Range +50°C to +130°C
A5-02-20 07-02-20 10 Bit Temperature Sensor Range -10°C to +41.2°C
A5-02-30 07-02-30 10 Bit Temperature Sensor Range -40°C to +62.3°C
A5-04-01 07-04-01 Range 0°C to +40°C and 0% to 100%
A5-04-02 07-04-02 Range -20°C to +60°C and 0% to 100%
A5-04-03 07-04-03 Range -20°C to +60°C 10bit-measurement and 0% to 100%
A5-06-01 07-06-01 Range 300lx to 60.000lx
A5-06-02 07-06-02 Range 0lx to 1.020lx
A5-06-03 07-06-03 10-bit measurement (1-Lux resolution) with range 0lx to 1000lx
A5-07-01 07-07-01 Occupancy with Supply voltage monitor
A5-07-02 07-07-02 Occupancy with Supply voltage monitor
A5-07-03 07-07-03 Occupancy with Supply voltage monitor and 10-bit illumination measurement
A5-08-01 07-08-01 Range 0lx to 510lx
A5-08-01 07-08-01 0°C to +51°C and Occupancy Button
A5-08-02 07-08-02 Range 0lx to 1020lx
A5-08-02 07-08-02 0°C to +51°C and Occupancy Button
A5-08-03 07-08-03 Range 0lx to 1530lx
A5-08-03 07-08-03 -30°C to +50°C and Occupancy Button
A5-09-01 07-09-01 CO Sensor (not in use)
A5-09-02 07-09-02 CO-Sensor 0 ppm to 1020 ppm
A5-09-04 07-09-04 CO2 Sensor
A5-09-05 07-09-05 VOC Sensor
A5-09-06 07-09-06 Radon
A5-09-07 07-09-07 Particles
A5-09-08 07-09-08 Pure CO2 Sensor
A5-10-01 07-10-01 Temperature Sensor
A5-10-01 07-10-01 Set Point
A5-10-01 07-10-01 Fan Speed and Occupancy Control
A5-10-02 07-10-02 Temperature Sensor
A5-10-02 07-10-02 Set Point
A5-10-02 07-10-02 Fan Speed and Day/Night Control
A5-10-03 07-10-03 Temperature Sensor
A5-10-03 07-10-03 Set Point Control
A5-10-04 07-10-04 Temperature Sensor
A5-10-04 07-10-04 Set Point and Fan Speed Control
A5-10-05 07-10-05 Temperature Sensor
A5-10-05 07-10-05 Set Point and Occupancy Control
A5-10-06 07-10-06 Temperature Sensor
A5-10-06 07-10-06 Set Point and Day/Night Control
A5-10-07 07-10-07 Temperature Sensor
A5-10-07 07-10-07 Fan Speed Control
A5-10-08 07-10-08 Temperature Sensor
A5-10-08 07-10-08 Fan Speed and Occupancy Control
A5-10-09 07-10-09 Temperature Sensor
A5-10-09 07-10-09 Fan Speed and Day/Night Control
A5-10-0A 07-10-0A Temperature Sensor
A5-10-0A 07-10-0A Set Point Adjust and Single Input Contact
A5-10-0B 07-10-0B Temperature Sensor and Single Input Contact
A5-10-0C 07-10-0C Temperature Sensor and Occupancy Control
A5-10-0D 07-10-0D Temperature Sensor and Day/Night Control
A5-10-10 07-10-10 Temperature and Humidity Sensor
A5-10-10 07-10-10 Set Point and Occupancy Control
A5-10-11 07-10-11 Temperature and Humidity Sensor
A5-10-11 07-10-11 Set Point and Day/Night Control
A5-10-12 07-10-12 Temperature and Humidity Sensor and Set Point
A5-10-13 07-10-13 Temperature and Humidity Sensor
A5-10-13 07-10-13 Occupancy Control
A5-10-14 07-10-14 Temperature and Humidity Sensor
A5-10-14 07-10-14 Day/Night Control
A5-10-15 07-10-15 10 Bit Temperature Sensor
A5-10-15 07-10-15 6 bit Set Point Control
A5-10-16 07-10-16 10 Bit Temperature Sensor
A5-10-16 07-10-16 6 bit Set Point Control;Occupancy Control
A5-10-17 07-10-17 10 Bit Temperature Sensor
A5-10-17 07-10-17 Occupancy Control
A5-10-18 07-10-18 Illumination
A5-10-18 07-10-18 Temperature Set Point
A5-10-18 07-10-18 Temperature Sensor
A5-10-18 07-10-18 Fan Speed and Occupancy Control
A5-10-19 07-10-19 Humidity
A5-10-19 07-10-19 Temperature Set Point
A5-10-19 07-10-19 Temperature Sensor
A5-10-19 07-10-19 Fan Speed and Occupancy Control
A5-10-1A 07-10-1A Supply voltage monitor
A5-10-1A 07-10-1A Temperature Set Point
A5-10-1A 07-10-1A Temperature Sensor
A5-10-1A 07-10-1A Fan Speed and Occupancy Control
A5-10-1B 07-10-1B Supply Voltage Monitor
A5-10-1B 07-10-1B Illumination
A5-10-1B 07-10-1B Temperature Sensor
A5-10-1B 07-10-1B Fan Speed and Occupancy Control
A5-10-1C 07-10-1C Illumination
A5-10-1C 07-10-1C Illumination Set Point
A5-10-1C 07-10-1C Temperature Sensor
A5-10-1C 07-10-1C Fan Speed and Occupancy Control
A5-10-1D 07-10-1D Humidity
A5-10-1D 07-10-1D Humidity Set Point
A5-10-1D 07-10-1D Temperature Sensor
A5-10-1D 07-10-1D Fan Speed and Occupancy Control
A5-10-1F 07-10-1F Temperature Sensor
A5-10-1F 07-10-1F Set Point
A5-10-1F 07-10-1F Fan Speed
A5-10-1F 07-10-1F Occupancy and Unoccupancy Control
A5-10-20 07-10-20 Temperature and Set Point with Special Heating States
A5-10-21 07-10-21 Temperature
A5-10-21 07-10-21 Humidity and Set Point with Special Heating States
A5-11-01 07-11-01 Lighting Controller
A5-11-02 07-11-02 Temperature Controller Output
A5-11-03 07-11-03 Blind Status
A5-11-04 07-11-04 Extended Lighting Status
A5-12-00 07-12-00 Counter
A5-12-01 07-12-01 Electricity
A5-12-02 07-12-02 Gas
A5-12-03 07-12-03 Water
A5-13-01 07-13-01 Weather Station
A5-13-02 07-13-02 Sun Intensity
A5-13-03 07-13-03 Date Exchange
A5-13-04 07-13-04 Time and Day Exchange
A5-13-05 07-13-05 Direction Exchange
A5-14-01 07-14-01 Single Input Contact (Window/Door)
A5-14-01 07-14-01 Supply voltage monitor
A5-14-02 07-14-02 Single Input Contact (Window/Door)
A5-14-02 07-14-02 Supply voltage monitor and Illumination
A5-14-03 07-14-03 Single Input Contact (Window/Door)
A5-14-03 07-14-03 Supply voltage monitor and Vibration
A5-14-04 07-14-04 Single Input Contact (Window/Door)
A5-14-04 07-14-04 Supply voltage monitor
A5-14-04 07-14-04 Vibration and Illumination
A5-14-05 07-14-05 Vibration/Tilt
A5-14-05 07-14-05 Supply voltage monitor
A5-14-06 07-14-06 Vibration/Tilt
A5-14-06 07-14-06 Illumination and Supply voltage monitor
A5-30-01 07-30-01 Single Input Contact
A5-30-01 07-30-01 Battery Monitor
A5-30-02 07-30-02 Single Input Contact
A5-30-03 07-30-03 4 Digital Inputs
A5-30-03 07-30-03 Wake and Temperature
A5-30-04 07-30-04 3 Digital Inputs
A5-30-04 07-30-04 1 Digital Input 8 Bits
A5-37-01 07-37-01 Demand Response
A5-38-08 07-38-08 Gateway
A5-38-09 07-38-09 Extended Lighting-Control
D5-00-01 06-00-01 Single Input Contact
F6-02-01 05-02-01 Light and Blind Control - Application Style 1
F6-02-02 05-02-02 Light and Blind Control - Application Style 2
F6-02-03 05-02-03 Light Control - Application Style 1
F6-02-04 05-02-04 Light and blind control ERP2
F6-03-01 05-03-01 Light and Blind Control - Application Style 1
F6-03-02 05-03-02 Light and Blind Control - Application Style 2
F6-04-01 05-04-01 Key Card Activated Switch
F6-04-02 05-04-02 Key Card Activated Switch ERP2
F6-05-01 05-05-01 Liquid Leakage Sensor (mechanic harvester)
F6-10-00 05-10-00 Window Contact Sensor
