Translation is in progress...
Not all topics are available at the moment and content links may be broken.
boolean EIB_DimValue (integer $InstanceID, integer $Value)| InstanceID | ID of the device to be switched |
| Value | Value 0..255, 0..100% |
| If the command succeeds, it returns TRUE, otherwise FALSE. |
Sends the dim value Value to the device with the ID InstanceID. Depending on configuration 0..255 (Standard) or 0..100 (Percent) will be passed as the value parameter.
EIB_DimValue(12345, 100); //Dimming to 100%
