Documentation
VoIP_GetConnection
Require: IP-Symcon >= 5.2
array VoIP_GetConnection (int $InstanceID, int $ConnectionID)
Parameters
| InstanceID | ID of the device to be switched |
| ConnectionID | ID of the connection to be switched |
Returns
Array with the following information
| Field | Data type | Description |
|---|---|---|
| ID | integer | ConnectionID |
| TimeStamp | integer | Time stamp of the call |
| Number | string | Number with which a connection was established |
| Direction | integer | Call direction: 0 = Incoming call, 1 = Outgoing call |
| Connected | boolean | Connection status: FALSE = not connected, TRUE = connected |
| Disconnected | boolean | Disconnection status: FALSE = not disconnected, TRUE = disconnected |
Description
Returns the information of the connection with ID ConnectionID of the VoIP instance with ID InstanceID.
---return---
Array with the following information
| Field | Data type | Description |
|---|---|---|
| ID | integer | ConnectionID |
| TimeStamp | integer | Time stamp of the c |
Example
// Returns information of the connection with ID 3.
print_r(VoIP_GetConnection(12345, 3));
// Sample output:
/*
Array
(
[ID] => 3
[TimeStamp] => 1566915689
[Number] => 045130500511
[Data] =>
[Direction] => 1
[Connected] => 1
[Disconnected] =>
)
*/
